Mini računar Q30600GPR3 S20 serija

Name: Mini računar Q30600GPR3 S20 serija
Brand: Qotom
SKU: Q30600GPR3-S20

Model: Q30600GPR3-S20

Ukupno LAN16

Brzina LAN-a1G RJ45

Serijski portovi1

Ključne specifikacije

CPU: Skylake / Kaby Lake / Kaby Lake-R
Memorija: DDR3L SO-DIMM · Maks. 8GB
LAN: 16
Skladište: mSATA, SATA

Kompatibilna matična ploča

MB4U86R-0600-D3

Pošalji upit

Q30611GPR3 Q30612GPR3 Q30631GPR3 Q30651GPR3 Q30671GPR3 Q30711GPR3 Q30712GPR3 Q30731GPR3 Q30751GPR3 Q30771GPR3 Q30811GPR3 Q30821GPR3 Q30831GPR3 Q30851GPR3 Q30871GPR3 Intel Celeron Pentium Core i3 Core i5 Core i7

Main Features

Intel 6th Skylake-U Processor
Intel 7th Kabylake-U Processor
Intel 8th Kabylake-R-U Processor
1 × Display Port, 1 × HDMI
2 × USB 3.0, 2 × USB 2.0
1 × mSATA, 1 × Mini PCIe, 1 × M.2, 1 × SATA 3.0
1 × RS-232 (RJ-45)
8 × Realtek Gigabit LAN
8 × Realtek RTL8153B Gigabit LAN

Srodni proizvodi

Mini računar Q71200G6 S18 serija

Q71200G6-S18

Mini računar Q30900SP S20 serija

Q30900SP-S20

Mini računar Q30900GP S20 serija

Q30900GP-S20

Mini računar Q30900GE S13 serija

Q30900GE-S13

Panel PC Q30600PPC S61 Series

Q30600PPC-S61

Mini PC Q20300S9 S20 serija

Q20300S9-S20

CPU	• Intel 6th Skylake-U Processor • Intel 7th Kabylake-U Processor • Intel 8th Kabylake-R-U Processor
CPU TDP	By CPU
Memorija	1 × DDR3L SO-DIMM Socket (Up to 8G, 1333/1600MHz)
Chipset	By CPU
Grafika	By CPU
LAN čipset	16 × Realtek Gigabit LAN
Watch Dog	Yes

Dugme za napajanje	1 × Power Button,1 × Reset Button
LED	1 × Power LED,1 × HDD LED
USB	2 × USB 3.0,2 × USB 2.0
Serijski port	1 × RS-232 Port (RJ-45)
Power	1 × DC Jack
Video izlaz	1 × HDMI,1 × Display Port

Tip	1 × 2.5-inch HDD/SSD
Tip	1 × Mini PCIe for mSATA SSD

Mini PCIe	1 × Mini PCIe (Only Support USB Device) Full-length for 4G Half-length for Wi-Fi
M.2	1 × M.2 for Wi-Fi (E key, Type: 2230)
Slot za SIM karticu	1
Jumper za automatsko pokretanje	Yes,1 × 3Pin, Pitch 2.54mm
DC-IN	No
Jumper za brisanje CMOS-a	Yes,1 × 3Pin, Pitch 2.0mm
GPIO	1,2 × 5Pin, Pitch 2.0mm
RS-485	0

Adapter za napajanje	12V4A
DC Priključak	5.5mm, 2.5mm

Mini PC serija

Serija matičnih ploča

NAS skladišna serija

OPS serija

Panel PC serija

Dodatna oprema

Mini računar Q30600GPR3 S20 serija

Ključne specifikacije

Kompatibilna matična ploča

Main Features

Procesorski sistem

Prednji I/O

Zadnji I/O

Skladište

Proširenje

Power

Uslovi okoline

Mehanički

Podrška za OS

Sadržaj pakovanja

Izbor porudžbine i specifikacije

BIOS & Firmware

Preuzimanje drajvera

Srodni proizvodi

Radna temp	0°C~50°C
Temperatura van rada	-20°C~80°C
Vlažnost	10%~90%

Materijal	Aluminium Alloy
Dimenzije	221 × 121 × 62mm
Težina	1.56kg
Montaža	VESA Mounting Bracket
Dimenzije pakovanja	285 × 260 × 93mm
Kensington brava	No
Način hlađenja	Fanless Design

Ordering Code	Code Name	Processor Type	Processor Number	Cores / Threads	Frequency	Cache	Graphics	TDP
Q30611GPR3-S20	Skylake	Celeron	3855U	2 / 2	1.6GHz	2M	Intel HD 510	15W
Q30612GPR3-S20	Skylake	Celeron	3955U	2 / 2	2.0GHz	2M	Intel HD 510	15W
Q30631GPR3-S20	Skylake	Core i3	6100U	2 / 4	2.3GHz	3M	Intel HD 520	15W
Q30651GPR3-S20	Skylake	Core i5	6200U	2 / 4	2.3GHz ~ 2.8GHz	3M	Intel HD 520	15W
Q30671GPR3-S20	Skylake	Core i7	6500U	2 / 4	2.5GHz ~ 3.1GHz	4M	Intel HD 520	15W
Q30711GPR3-S20	Kaby Lake	Celeron	3865U	2 / 2	1.8GHz	2M	Intel HD 610	15W
Q30712GPR3-S20	Kaby Lake	Celeron	3965U	2 / 2	2.2GHz	2M	Intel HD 610	15W
Q30731GPR3-S20	Kaby Lake	Core i3	7100U	2 / 4	2.4GHz	3M	Intel HD 620	15W
Q30751GPR3-S20	Kaby Lake	Core i5	7200U	2 / 4	2.5GHz ~ 3.1GHz	3M	Intel HD 620	15W
Q30771GPR3-S20	Kaby Lake	Core i7	7500U	2 / 4	2.7GHz ~ 3.5GHz	4M	Intel HD 620	15W
Q30811GPR3-S20	Kaby Lake R	Celeron	3867U	2 / 2	1.8GHz	2M	Intel HD 610	15W
Q30821GPR3-S20	Kaby Lake R	Pentium	4417U	2 / 2	2.3GHz	2M	Intel HD 610	15W
Q30831GPR3-S20	Kaby Lake R	Core i3	8130U	2 / 4	2.0GHz ~ 3.40GHz	4M	Intel UHD 620	15W
Q30851GPR3-S20	Kaby Lake R	Core i5	8250U	4 / 8	1.6GHz ~ 3.4GHz	6M	Intel UHD 620	15W
Q30871GPR3-S20	Kaby Lake R	Core i7	8550U	4 / 8	1.8GHz ~ 4.0GHz	8M	Intel UHD 620	15W
