Mini PC Q10900S6 1U13 Series

Name: Mini PC Q10900S6 1U13 Series
Brand: Qotom
SKU: Q10900S6-1U13

Model: Q10900S6-1U13

Total LAN6

LAN Speed2.5G RJ45 / 10G RJ45 / 10G SFP+

Serial Ports1

Key Specs

CPU: Alder lake N / Twin Lake
Memory: DDR5 SO-DIMM · Max 48GB
LAN: 6
Storage: M.2 Mkey

Compatible Motherboard

MB4J61X-0900

Send Inquiry Buy Now

Q10911S6 Q10921S6 Q10922S6 Q10923S6 Q10924S6 Q10931S6 Q10932S6 Q11022S6 Q11023S6 Q11031S6 Q11032S6 Intel Alder Lake-N Twin Lake Pentium Celeron ATOM X7425E N50 N97 N100 N200 N300 N305 N150 N250 N350 N355

Main Features

Intel Alder Lake-N Processor
Intel Twin Lake-N Processor
1 × HDMI, 1 × Display Port
2 × USB 3.0 , 2 × USB 2.0
2 × M.2
1 × RS-232 (RJ45)
2 × Intel I226-V 2.5G LAN
2, Intel X540 10G LAN
2, Intel 82599ES 10G SFP+

Related Products

Mini PC Q71200G6 S18 Series

Q71200G6-S18

Mini PC Q30900SP S20 Series

Q30900SP-S20

Mini PC Q30900GP S20 Series

Q30900GP-S20

Mini PC Q30900GE S13 Series

Q30900GE-S13

Mini PC Q20300S9 S20 Series

Q20300S9-S20

Mini PC Q10900H6 1U16 Series

Q10900H6-1U16

CPU	Intel Alder Lake-N Processor Intel Twin Lake-N Processor
CPU TDP	By CPU
Memory	1 × DDR5 SO-DIMM Socket (Up to 48G)
Chipset	By CPU
Graphics	By CPU
LAN Chipset	2 × Intel I226-V 2.5G LAN 2, Intel X540 10G LAN, (10GbE/1GbE) 2, Intel 82599ES 10G SFP+,(10GbE/1GbE)
Watch Dog	Yes

Power Button	1 × Power Button, 1 × Reset Button
LED	1 × Power LED,1 × HDD LED
USB	2 × USB 3.0, 2 × USB 2.0
Serial Port	1 × Connector, RS-232 (RJ-45)

DC-IN	1
Display	1× HDMI,1× Display Port
SFP+	2 × 10G SFP+ Both interfaces support up to 12Gbps
Ethernet	2 × 10G RJ45 Both interfaces support up to 12Gbps
Ethernet	2 × 2.5G RJ45

M.2	1 × M.2 for Wi-Fi (E key, Type: 2230)
AutoStart Jumper	Yes, 1 × 3Pin, Pitch 2.0mm
eMMC	Option
USB 2.0 Header	2, 2 × 5Pin, Pitch 2.0mm
USB 3.0 Header	1, 2 × 5Pin, Pitch 2.0mm,Option
CMOS Clear Jumper	Yes, 1 × 3Pin, Pitch 2.0mm
Front Panel Header	1, 2 × 5Pin, Pitch 2.0mm
Power Header	1, 1 × 2Pin, Pitch 3.5mm, Phoenix 2Pin

Power Adapter	AC 100-240V by Default
DC Jack	DC 12V (5.5mm, 2.5mm)

Mini PC Series

Motherboard Series

NAS Storage Series

OPS Series

Panel PC Series

Accessories

Mini PC Q10900S6 1U13 Series

Key Specs

Compatible Motherboard

Main Features

Processor System

Front I/O

Rear I/O

Storage

Expansion

Power

Environmental

Mechanical

OS Support

Package Contents

Order & Specification Selection

BIOS & Firmware

Driver Downloads

Related Products

Operating Temp	0°C~50°C
Non-Operating Temp	-20°C~80°C
Humidity	10%~90%

Material	Aluminium Alloy
Dimension	440 × 122 × 44mm
Weight	1.42kg
Mounting	No
Packaging Dimension	545 × 180 × 90mm
Kensington Lock	No
Cooling Mode	Fan

Ordering Code	Code Name	Processor Type	Processor Number	Cores / Threads	Frequency	Cache	Graphics	TDP
Q10911S6-1U13	Alder lake-N	-	N50	2 / -	3.4GHz	6M	Intel UHD Graphics	6W
Q10921S6-1U13	Alder lake-N	-	N97	4 / -	3.6GHz	6M	Intel UHD Graphics	12W
Q10922S6-1U13	Alder lake-N	-	N100	4 / 4	3.4GHz	6M	Intel UHD Graphics	6W
Q10923S6-1U13	Alder lake-N	-	N200	4 / 4	3.7GHz	6M	Intel UHD Graphics	6W
Q10924S6-1U13	Alder lake-N	Atom	X7425E	4 / 4	3.4GHz	6M	Intel UHD Graphics	12W
Q10931S6-1U13	Alder lake-N	Core i3	N300	8 / 8	3.8GHz	6M	Intel UHD Graphics	7W
Q10932S6-1U13	Alder lake-N	Core i3	N305	8 / 8	3.8GHz	6M	Intel UHD Graphics	15W
Q11022S6-1U13	Twin Lake-N	-	N150	4 / 4	3.6GHz	6M	Intel Graphics	6W
Q11023S6-1U13	Twin Lake-N	-	N250	4 / 4	3.8GHz	6M	Intel Graphics	6W
Q11031S6-1U13	Twin Lake-N	Core i3	N350	8 / 8	3.9GHz	6M	Intel Graphics	7W
Q11032S6-1U13	Twin Lake-N	Core i3	N355	8 / 8	3.9GHz	6M	Intel Graphics	15W
