Mini PC Q10100G4 S08 Series

Model: Q10100G4-S08

Total LAN4
LAN Speed1G RJ45

Key Specs

CPU
Bay Trail
Memory
DDR3L SO-DIMM · Max 8GB
LAN
4
Storage
mSATA, SATA

Compatible Motherboard

MB2J401-0100
MB2J401-0100
Send Inquiry Buy Now
Q180G4NQ190G4NQ192G4NQ193G4NQ195G4NQ10111G4NQ10121G4NQ10122G4NQ10123G4NQ10134G4NIntelBay TrailPentiumCeleronATOMN2840J1800J1900N2920N2930N3540

Main Features

  • Intel Bay Trail Processor

  • 1 × VGA

  • 1 × USB 3.0,3 × USB 2.0,1 × SATA 3.0

  • 1 × Mini PCIe,1 × mSATA

  • 4 × Intel I211-AT/I210-AT Gigabit LAN

Processor System

CPUIntel Bay Trail Processor
CPU TDPBy CPU
Memory1 × DDR3L SO-DIMM Socket (Up to 8G, 1333/1600MHz)
ChipsetBy CPU
GraphicsBy CPU
LAN Chipset4 × Intel I211-AT/I210-AT Gigabit LAN
AudioNo
Watch DogNo

Front I/O

Power Button1
LED1 × Power LED
VGA1
USB1 × USB 3.0,3 × USB 2.0
AudioNo

Rear I/O

Power1 × DC Jack
LAN4 × Intel I211-AT/I210-AT Gigabit LAN
LED1 × Power LED,1 × HDD LED

Storage

Type1 × 2.5-inch HDD/SSD 1 × Mini PCIe for mSATA SSD

Expansion

mSATA1 × Full-length Mini PCIe for SSD
Mini PCIe1 × Mini PCIe Full-length for 4G, Half-length for Wi-Fi (Default Only Support USB Device)
SIM Card Slot1
AutoStart JumperYes,1 × 3Pin, Pitch 2.54mm
DC-INNo

Power

Power Adapter12V3A
DC Jack5.5mm, 2.5mm

Environmental

Operating Temp0°C~50°C
Non-Operating Temp-20°C~80°C
Humidity10%~90%

Mechanical

MaterialAluminium Alloy
Dimension155 × 127 × 48mm
Weight0.88kg
MountingVESA Mounting Bracket
Packaging Dimension261 × 218 × 75mm
Kensington LockNo
Cooling ModeFanless Design

OS Support

OSWindows 7, Windows 8, Windows 10, Linux

Package Contents

  • Mini PC × 1
  • Power Adapter × 1
  • AC Power Cable × 1
  • VESA Mount × 1
  • SATA Combo Cable × 1
  • Screw Kit × 1

* Actual package contents may vary. Subject to change without notice.

Order & Specification Selection

Ordering CodeLegacy ModelCode NameProcessor TypeProcessor NumberCores / ThreadsFrequencyCacheGraphicsTDPDatasheet
Q10121G4-S08 Q190G4 Bay trail Celeron J1900 4 / 4 2.00Ghz ~ 2.42Ghz 2M Intel HD Graphics 10W
Q10122G4-S08 Q192G4 Bay trail Celeron N2920 4 / 4 1.86Ghz ~ 2.00Ghz 2M Intel HD Graphics 7.5W
Q10123G4-S08 Q193G4 Bay trail Celeron N2930 4 / 4 1.83Ghz ~ 2.16Ghz 2M Intel HD Graphics 7.5W
Q10134G4-S08 Q195G4 Bay trail Pentium N3540 4 / 4 2.16Ghz ~ 2.66Ghz 2M Intel HD Graphics 7.5W
