Mini PC Q30600GER3X S20 Series

Name: Mini PC Q30600GER3X S20 Series
Brand: Qotom
SKU: Q30600GER3X-S20

Model: Q30600GER3X-S20

Total LAN8

LAN Speed1G RJ45

Serial Ports6

Q30600GER3X-S20 brings 8×Gigabit LAN, 6 serial ports and DDR3L memory with Intel Core processor options to industrial communication and embedded control projects. Deployment scenarios range from production terminals, instrumentation and serial peripherals.

Key Specs

CPU: Skylake / Kaby Lake / Kaby Lake-R
Memory: DDR3L SO-DIMM · Max 8GB
LAN: 8
Storage: mSATA, SATA

Compatible Motherboard

MB4U86R-0600-D3

Send Inquiry

Main Features

Intel 6th Skylake-U Processor
Intel 7th Kabylake-U Processor
Intel 8th Kabylake-R-U Processor
1 × Display Port, 1 × HDMI
4 × USB 3.0
1 × mSATA, 1 × Mini PCIe, 1 × M.2, 1 × SATA 3.0
1 × RS-232 (RJ-45), 5 × RS-232 (DB9)
8 × Realtek Gigabit LAN

Related Products

Mini PC Q71200G6 S18 Series

Q71200G6-S18

Mini PC Q30900SP S20 Series

Q30900SP-S20

Mini PC Q30900GP S20 Series

Q30900GP-S20

Mini PC Q30900GE S13 Series

Q30900GE-S13

Panel PC Q30600PPC S61 Series

Q30600PPC-S61

Mini PC Q20300S9 S20 Series

Q20300S9-S20

CPU	• Intel 6th Skylake-U Processor • Intel 7th Kabylake-U Processor • Intel 8th Kabylake-R-U Processor
CPU TDP	By CPU
Memory	1 × DDR3L SO-DIMM Socket (Up to 8G, 1333/1600MHz)
Chipset	By CPU
Graphics	By CPU
LAN Chipset	8 × Realtek Gigabit LAN
Watch Dog	Yes

Power Button	1 × Power Button,1 × Reset Button
LED	1 × Power LED,1 × HDD LED
USB	4 × USB 3.0
Serial Port	1 × RS-232 Port (RJ-45)
Power	1 × DC Jack
Video Output	1 × HDMI,1 × Display Port

Type	1 × 2.5-inch HDD/SSD
Type	1 × Mini PCIe for mSATA SSD

Mini PCIe	1 × Mini PCIe (Only Support USB Device) Full-length for 4G Half-length for Wi-Fi
M.2	1 × M.2 for Wi-Fi (E key, Type: 2230)
SIM Card Slot	1
AutoStart Jumper	Yes,1 × 3Pin, Pitch 2.54mm
DC-IN	No
CMOS Clear Jumper	Yes,1 × 3Pin, Pitch 2.0mm
GPIO	1,2 × 5Pin, Pitch 2.0mm
RS-485	COM3/4 can be set up as RS-485

Power Adapter	12V4A
DC Jack	5.5mm, 2.5mm

Mini PC Q30600GER3X S20 Series

Key Specs

Compatible Motherboard

Main Features

Processor System

Front I/O

Rear I/O

Storage

Expansion

Power

Environmental

Mechanical

OS Support

Package Contents

Order & Specification Selection

BIOS & Firmware

Driver Downloads

Related Products

LAN	8 × Realtek Gigabit LAN
Serial Port	5 × RS-232 Port (DB9) (COM3/COM4 Support 5V/12V)

Operating Temp	0°C~50°C
Non-Operating Temp	-20°C~80°C
Humidity	10%~90%

Material	Aluminium Alloy
Dimension	221 × 121 × 62mm
Weight	1.45kg
Mounting	VESA Mounting Bracket
Packaging Dimension	285 × 260 × 93mm
Kensington Lock	No
Cooling Mode	Fanless Design

Ordering Code	Code Name	Processor Type	Processor Number	Cores / Threads	Frequency	Cache	Graphics	TDP
Q30611GER3X-S20	Skylake	Celeron	3855U	2 / 2	1.6GHz	2M	Intel HD 510	15W
Q30612GER3X-S20	Skylake	Celeron	3955U	2 / 2	2.0GHz	2M	Intel HD 510	15W
Q30631GER3X-S20	Skylake	Core i3	6100U	2 / 4	2.3GHz	3M	Intel HD 520	15W
Q30651GER3X-S20	Skylake	Core i5	6200U	2 / 4	2.3GHz ~ 2.8GHz	3M	Intel HD 520	15W
Q30671GER3X-S20	Skylake	Core i7	6500U	2 / 4	2.5GHz ~ 3.1GHz	4M	Intel HD 520	15W
Q30711GER3X-S20	Kaby Lake	Celeron	3865U	2 / 2	1.8GHz	2M	Intel HD 610	15W
Q30712GER3X-S20	Kaby Lake	Celeron	3965U	2 / 2	2.2GHz	2M	Intel HD 610	15W
Q30731GER3X-S20	Kaby Lake	Core i3	7100U	2 / 4	2.4GHz	3M	Intel HD 620	15W
Q30751GER3X-S20	Kaby Lake	Core i5	7200U	2 / 4	2.5GHz ~ 3.1GHz	3M	Intel HD 620	15W
Q30771GER3X-S20	Kaby Lake	Core i7	7500U	2 / 4	2.7GHz ~ 3.5GHz	4M	Intel HD 620	15W
Q30811GER3X-S20	Kaby Lake R	Celeron	3867U	2 / 2	1.8GHz	2M	Intel HD 610	15W
Q30821GER3X-S20	Kaby Lake R	Pentium	4417U	2 / 2	2.3GHz	2M	Intel HD 610	15W
Q30831GER3X-S20	Kaby Lake R	Core i3	8130U	2 / 4	2.0GHz ~ 3.40GHz	4M	Intel UHD 620	15W
Q30851GER3X-S20	Kaby Lake R	Core i5	8250U	4 / 8	1.6GHz ~ 3.4GHz	6M	Intel UHD 620	15W
Q30871GER3X-S20	Kaby Lake R	Core i7	8550U	4 / 8	1.8GHz ~ 4.0GHz	8M	Intel UHD 620	15W
