Motherboard MB6U419-0900 Series

Name: Motherboard MB6U419-0900 Series
Brand: Qotom
SKU: MB6U419-0900

Model: MB6U419-0900

Total LAN4

LAN Speed2.5G RJ45

Key Specs

CPU: Whiskey Lake / Coffee Lake / Comet lake
Memory: DDR4 SO-DIMM · Max 64GB
LAN: 4
Storage: M.2 Mkey, SATA
Board Size: 120x200

Compatible Systems

Q30900DS-S14

Send Inquiry

Main Features

Intel 8th Whiskey Lake-U Processor
Intel 8th Coffee Lake-U Processor
Intel 10th Comet lake-U Processor
2 × HDMI
3 × USB 3.0, 1 × USB 2.0, 1 × Type C
2 × M.2
4 × Intel I225-V/I226-V 2.5G LAN

Related Products

Motherboard MB7UT1X-1500 Series

MB7UT1X-1500

Mini PC Q30900SP S20 Series

Q30900SP-S20

Mini PC Q30900GP S20 Series

Q30900GP-S20

Mini PC Q30900P S08 Series

Q30900P-S08

Mini PC Q30900GE S13 Series

Q30900GE-S13

Mini PC Q30900X S20 Series

Q30900X-S20

CPU	• Intel 8th Whiskey Lake-U Processor • Intel 8th Coffee Lake-U Processor • Intel 10th Comet lake-U Processor
Chipset	By CPU
Dimension	120 × 200mm
Core Number	By CPU
Max. Speed	By CPU
L2 Cache	By CPU
BIOS	UEFI

Technology	DDR4 2133/2400MHz SDRAM
Max.	64GB
Socket	2 × SO-DIMMs

Controller	By CPU
VRAM	Shared Memory
Display Port	0
HDMI	2 (Support HDMI 1.4a)
Multi Display	Yes

Interface	100/1000/2500Mbps
Controller	4 × Intel I225-V/I226-V 2.5G LAN
Connector	4 × RJ-45

Power Button	1 × Power Button, 1 × Reset Button
LED	1 × Power LED, 1 × HDD LED
LED	1 × LAN LED
USB	2 × USB 3.0
USB	1 × USB 3.0, 1 × USB 2.0
DC-IN	1
Type C	1, USB 3.0 and Display Port
HDMI	2
Ethernet	4

Mini PC Series

Motherboard Series

NAS Storage Series

OPS Series

Panel PC Series

Accessories

Motherboard MB6U419-0900 Series

Key Specs

Compatible Systems

Main Features

Processor System

Memory

Graphics

Ethernet

Audio

Front I/O

Storage

Expansion

Internal Connector

Watchdog Timer

Power

Environmental

Accessories

OS Support

Package Contents

Order & Specification Selection

BIOS & Firmware

Driver Downloads

Related Products

M.2	1 × M.2 for SSD (M key, Type: 2280, PCIe 3.0 × 4)
M.2	1 × M.2 for SSD (M key, Type: 2280, PCIe 3.0 × 1)

TPM	1 (Option)
PCIe	1, PCIe slot (Type: X4,PCIe 3.0 × 1, SATA 3.0 × 2)
Serial Port	1, 2 × 5Pin, Pitch 2.0mm (Option)
AutoStart Jumper	Yes, 1 × 3Pin, Pitch 2.54mm
Clear CMOS Jumper	Yes, 1 × 3Pin, Pitch 2.0mm
GPIO Header	1, 2 × 5Pin, Pitch 2.0mm
GPIO Power Select	Yes, 1 × 3Pin, Pitch 2.0mm
USB 2.0 Header	2, 2 × 5Pin, Pitch 2.0mm
Front Panel Header	1, 2 × 5Pin, Pitch 2.0mm
Power Header	1, 1 × 2Pin, Pitch 3.5mm, Phoenix 2Pin (Option)

Output	From Super I/O to Drag RESETCON#
Interval	256 Segments,0,1,2,3,,,255 sec/min

Ordering Code	Code Name	Processor Type	Processor Number	Cores / Threads	Frequency	Cache	Graphics	TDP
MB6U419-912	Whiskey Lake	Celeron	4305U	2 / 2	2.2GHz	2M	Intel UHD Graphics	15W
MB6U419-921	Whiskey Lake	Pentium	5405U	2 / 4	2.3GHz	2M	Intel UHD Graphics	15W
MB6U419-931	Whiskey Lake	Core i3	8145U	2 / 4	2.1GHz ~ 3.9GHz	4M	Intel UHD Graphics	15W
MB6U419-951	Whiskey Lake	Core i5	8265U	4 / 8	1.6GHz ~ 3.9GHz	6M	Intel UHD Graphics	15W
MB6U419-971	Whiskey Lake	Core i7	8565U	4 / 8	1.8GHz ~ 4.6GHz	8M	Intel UHD Graphics	15W
MB6U419-952	Coffee Lake	Core i5	8260U	4 / 8	1.6GHz ~ 3.9GHz	6M	Intel UHD Graphics 620	15W
MB6U419-1011	Comet Lake	Celeron	5205U	2 / 2	1.9GHz	2M	Intel UHD Graphics	15W
MB6U419-1012	Comet Lake	Celeron	5305U	2 / 2	2.3GHz	2M	Intel UHD Graphics	15W
MB6U419-1021	Comet Lake	Pentium	6405U	2 / 4	2.4GHz	2M	Intel UHD Graphics	15W
MB6U419-1031	Comet Lake	Core i3	10110U	2 / 4	2.1GHz ~ 4.1GHz	4M	Intel UHD Graphics	15W
MB6U419-1051	Comet Lake	Core i5	10210U	4 / 8	1.6GHz ~ 4.2GHz	6M	Intel UHD Graphics	15W
MB6U419-1071	Comet Lake	Core i7	10610U	4 / 8	1.8GHz ~ 4.9GHz	8M	Intel UHD Graphics	15W
MB6U419-1072	Comet Lake	Core i7	10810U	6 / 12	1.1GHz ~ 4.9GHz	12M	Intel UHD Graphics	15W
MB6U419-1073	Comet Lake	Core i7	10710U	6 / 12	1.1GHz ~ 4.7GHz	12M	Intel UHD Graphics	15W
MB2U419-1074	Comet Lake	Core i7	10510U	4 / 8	1.8GHz ~ 4.9GHz	8M	Intel UHD Graphics	15W
